Product testing
● ① Upon the welding of the frame and the bumpy plate, the leak testing is conducted on the weld seam in accordance with the kerosene leakage testing method as mentioned in NB/T 47003.1-2022.
● ② The flatness of the bipolar plate is controlled with a dedicated detection platform, and the thickness of the bipolar plate coating is detected with the X-ray fluorescence spectrometer.
● ③ The weld seam of the separation and purification system is detected for flaws in strict accordance with the requirements of the Pressure Piping Code (GB/T20801).
Experimental verification
● ① To focus on the development, incubation and application of the core technology for hydrogen production from electrolytic water, including electrode, membrane, new structures, and PEM electrolytic water hydrogen production technology
● ② To provide experimental basis for the selection and innovative research and development of electrodes. Functions: Fast inspection platform for electrode performance, fast inspection platform for electrode parameters, comprehensive testing platform
● ③ To provide experimental basis for the selection and technical demonstration of membrane materials. Functions: Membrane material parameter characterization platform, membrane material performance testing platform, development incubation platform
● ④ To provide low-cost and fast response parameters of "emulation → optimization" for core components such as electrodes. Functions: Core component parameter acquisition platform, operation parameter acquisition platform, component optimization verification platform
Testing center
● ① To build a systematic and standardized experiment-test-research and development system including electrochemical testing laboratory, material research development and production center and hydrogen production system machine testing site
Base on the SHDP system, we have built and upgraded 7 core capabilities, including integrated design, material development, emulation analysis, test verification, electrical control, manufacturing process, and hydrogen safety design, and constructed the Hydrogen Energy Equipment Research and Development Center and the Integrated Testing Platform for 20MW Electrolyzers lead the the development of hydrogen energy technology.
Sany Hydrogen Energy Equipment R&D Testing Center
